Grandstream GWN7660ELR Outdoor Long-Range Wi‑Fi 6 AP | AX3000, 2.5G SFP & 300m Range

Grandstream GWN7660ELR: Enterprise‑Grade Long‑Range Outdoor Wi‑Fi 6 Access Point

The Grandstream GWN7660ELR is a high‑performance outdoor long‑range Wi‑Fi 6 access point built for demanding enterprise environments. It is designed to provide reliable, high‑speed wireless coverage across large outdoor areas while withstanding the country‘s extreme heat, monsoon rains, and dust‑laden winds.

Blazing Fast Wi‑Fi 6 Performance

The GWN7660ELR leverages the latest 802.11ax (Wi‑Fi 6) standard, delivering an aggregate wireless throughput of 3 Gbps (573.5 Mbps on 2.4GHz and 2.4 Gbps on 5GHz). Its dual‑band 2×2:2 MIMO with OFDMA technology enables efficient multi‑user data transmission, reducing latency and improving network capacity – even when dozens of devices are connected simultaneously.

Unmatched Outdoor Range & Coverage

With a coverage range of 300 metres in open outdoor environments, a single GWN7660ELR can deliver seamless Wi‑Fi to large areas such as university campuses, hotel gardens, industrial yards, sports fields, and sprawling office complexes. It supports 256 concurrent Wi‑Fi client devices, making it an ideal choice for high‑density outdoor deployments.

Built to Survive Harsh Weather

The GWN7660ELR is engineered to withstand the elements. Its IP67‑rated weatherproof and dust‑proof casing provides complete protection against dust ingress and powerful water jets – it can survive being submerged in 1 metre of water for 30 minutes. The access point operates reliably in temperatures from -30°C to 60°C, ensuring stable performance through scorching Pakistani summers, monsoon flooding and dusty construction sites.

Flexible High‑Speed Connectivity

The AP is equipped with dual network ports – a 1 Gbps RJ45 port and a 2.5 Gbps SFP port – providing a total of 3.5 Gbps wired throughput (2.5G SFP + 1G RJ45). The SFP port allows for fibre optic uplinks to a core network, ensuring high‑speed backhaul even when the AP is installed far from the network closet. Power is delivered via PoE/PoE+ (802.3af/at) with a maximum consumption of only 13W, so a single Ethernet cable carries both power and data.

Advanced Security & Free Centralised Management

The GWN7660ELR protects your network with WPA3 encryption, supported alongside WPA/WPA2‑PSK and WPA/WPA2‑Enterprise. Device‑level security includes anti‑hacking secure boot, which prevents unauthorised firmware from loading, digitally signed critical data/control lockdown, a unique security certificate for each unit, and a random default password. Management is free and flexible:

• Built‑in embedded controller – manages up to 50 local GWN access points via the AP‘s web interface

• GDMS Networking – free cloud platform for zero‑touch provisioning, real‑time monitoring and unlimited AP management

• GWN Manager – free on‑premise software controller for organisations that prefer local management

Additional Enterprise Features

• 5 internal antennas – integrated design for optimised signal coverage without external components that can snag or break

• Bluetooth Low Energy (BLE) 5.2 – supports location‑based services and simplifies onboarding using the GWN app

• Advanced QoS – prioritises low‑latency real‑time applications such as VoIP calls, video conferencing and cloud collaboration

• Mesh networking – wireless uplink capability for deployments where cabling is difficult (e.g., across a sports field or between buildings on a campus where trenching is impractical)

• 32 SSIDs (16 per band) – create separate virtual networks for employees, guests, IoT devices and secure traffic

• Captive portal support – ideal for public Wi‑Fi hotspots

• Wall or pole mount – included mounting kit can be adjusted and rotated up to 60° for optimal antenna orientation

Key Specifications at a Glance

• Wi‑Fi Standard: 802.11ax (Wi‑Fi 6), backward compatible with a/b/g/n/ac

• Aggregate Throughput: Up to 3 Gbps (2.4GHz: 573.5 Mbps, 5GHz: 2.4 Gbps)

• Client Capacity: 256+ concurrent Wi‑Fi clients

• Coverage Range: Up to 300 metres (outdoor open area)

• Antennas: 5 internal antennas (2.4GHz: 5.5 dBi gain; 5GHz: 6 dBi gain)

• Ethernet Ports: 1× 10/100/1000 Mbps RJ45, 1× 2.5G SFP

• Power: PoE / PoE+ (802.3af/at), max consumption 13W

• Weatherproofing: IP67 (dust‑tight, protected against immersion up to 1m)

• Operating Temperature: -30°C to 60°C

• Security: WPA3, WPA/WPA2‑PSK, WPA/WPA2‑Enterprise, secure boot

• Bluetooth: BLE 5.2

• Management: Embedded controller (50 APs), GDMS Networking (free cloud), GWN Manager (on‑premise)

• SSIDs: 32 total, 16 per radio

• Dimensions: 270 mm × 230 mm × 57 mm

• Unit Weight: 1.0 kg (approx.)

• Mounting: Wall or pole mount (kits included, adjustable 60°)

• Certifications: FCC, CE, RCM, IC
