Grandstream GWN7664ELR AX6000 Outdoor Wi‑Fi 6 AP | 6 Gbps & 300m Range

Grandstream GWN7664ELR: Enterprise‑Grade Outdoor Long‑Range AX6000 Wi‑Fi 6 Access Point

The Grandstream GWN7664ELR is a high‑performance, outdoor long‑range 802.11ax Wi‑Fi 6 access point purpose‑built for medium‑to‑large businesses and enterprises that need to deliver reliable, high‑capacity wireless coverage across challenging outdoor spaces.

Blazing Fast AX6000 Speeds with 4×4:4 MU‑MIMO

The GWN7664ELR is an AX6000 class access point, offering a combined 6 Gbps aggregate wireless throughput (up to 1,147 Mbps on the 2.4 GHz band and up to 4.8 Gbps on the 5 GHz band). Its dual‑band 4×4:4 MU‑MIMO and DL/UL OFDMA technology allow the access point to communicate with multiple client devices simultaneously, dramatically reducing network congestion and latency. The 8 internal antennas provide exceptional gain (2.4 GHz: 3.5 dBi; 5 GHz: 5 dBi) and an optimised radiation pattern for long‑range coverage.

Long Range, High Density & Uncompromising Performance

The GWN7664ELR delivers a 300‑metre coverage range, making it ideal for covering large outdoor areas. It supports up to 512 concurrent Wi‑Fi client devices, so you can confidently deploy it in high‑density environments such as:

• University and corporate campuses – reliable connectivity across quadrangles, walkways and outdoor event spaces

• Hotel and resort grounds – seamless guest Wi‑Fi around pools, gardens and outdoor venues

• Industrial yards and warehouses – robust M2M/IoT connectivity for fleet management, sensors and handheld terminals

• Stadiums and public spaces – low‑latency connectivity for thousands of concurrent users.

2.5G Fibre Uplink & PoE+ Simplified Installation

The GWN7664ELR includes a 2.5 Gigabit RJ45 Ethernet port and a 2.5 Gigabit SFP fibre port, offering a total of 5 Gbps aggregate wired throughput – ensuring that your wireless speeds are never limited by the backhaul | . The SFP port provides a high‑speed fibre uplink, ideal for long‑distance back‑haul across large properties.

Power is delivered via PoE+ (802.3at) through the 2.5G RJ45 port, simplifying cabling. Maximum power consumption is 24W. For installations without PoE+ infrastructure, an optional 12V DC power adapter can be used (sold separately).

Built to Survive Pakistan’s Weather: IP67 & Extreme Temperatures

The GWN7664ELR is engineered to withstand the harshest outdoor conditions. Its IP67‑rated weatherproof casing provides complete protection against dust, powerful water jets and even temporary immersion. It is also designed to operate reliably in temperatures from -30 °C to 60 °C, ensuring stable performance through Pakistan‘s scorching summers, monsoon rains and sandstorms. In addition, waterproof cable glands and O‑rings are included to seal both the RJ45 and SFP interfaces against moisture ingress.

Enterprise‑Grade Security, Bluetooth BLE & Free Cloud Management

The access point supports WPA3 encryption (the latest Wi‑Fi security standard), along with WPA/WPA2‑PSK and WPA/WPA2‑Enterprise. Hardware‑level security features include anti‑hacking secure boot, digitally signed critical data, a unique security certificate and a random default password per device.

The GWN7664ELR also includes Bluetooth Low Energy (BLE) 5.2, enabling location‑based services and simplifying device discovery and onboarding via the GWN mobile app.

Management is completely flexible and free:

• Embedded Controller: Built into the AP’s web UI, it can manage up to 50 GWN series APs without any additional hardware or licensing.

• GDMS Networking: Grandstream‘s free cloud platform provides zero‑touch provisioning, real‑time monitoring, bulk firmware upgrades and advanced analytics across an unlimited number of APs – ideal for multi‑site businesses and managed service providers.

• GWN Manager: A free on‑premise software controller for organisations that prefer local management.

Advanced QoS prioritises low‑latency real‑time applications such as voice‑over‑Wi‑Fi, video conferencing and collaboration tools. The GWN7664ELR also supports mesh networking, captive portal, airtime fairness, band steering and other advanced Wi‑Fi features.

Key Technical Specifications at a Glance

• Wireless Standard: 802.11ax (Wi‑Fi 6), backward compatible with 802.11a/b/g/n/ac

• Aggregate Throughput: 6 Gbps (2.4 GHz: 1,147 Mbps; 5 GHz: 4.8 Gbps)

• MIMO: 4×4:4 MU‑MIMO on both bands with DL/UL OFDMA

• Client Capacity: 512 concurrent devices

• Coverage Range: Up to 300 metres

• Antennas: 8 internal (2.4 GHz gain 3.5 dBi, 5 GHz gain 5 dBi)

• Ethernet Ports: 1× 2.5G RJ45 (PoE+ input) + 1× 2.5G SFP

• Power: PoE+ (802.3at), max consumption 24W

• Bluetooth: BLE 5.2

• Weatherproof Rating: IP67 (dust‑tight, protected against immersion up to 1 m)

• Security: WPA3, secure boot, unique certificate, random default password

• Management: Embedded controller (50 APs), GDMS Networking (unlimited, cloud), GWN Manager (unlimited, on‑premise)

• Mounting: Wall or pole mount (kits included)

• Dimensions: 260 mm × 310 mm × 59 mm

• Unit Weight: 1.445 kg (approx.)

• Operating Temperature: -30 °C to 60 °C

• Certifications: FCC, CE, RCM, IC
