Grandstream GWN7806P: Build a Powerful, High‑Capacity Enterprise Network
The Grandstream GWN7806P is the definitive high‑density switch for small‑to‑medium enterprises looking to build a future‑proof, manageable, and ultra‑reliable network core. Designed primarily for Layer 2+ switching, it provides the raw power and intelligent features needed to support converged networks of hundreds of devices.
Massive PoE+ Capacity for All Edge Devices
With 48 Gigabit PoE+ ports (802.3af/at), the GWN7806P delivers a total power budget of 400W and up to 30W per port. This provides sufficient power to connect and power an entire floor of VoIP phones, Wi‑Fi 6/7 access points (including Grandstream GWN7670, GWN7801P), and 4K IP cameras without needing extra power adapters or injectors. The smart dynamic PoE control automatically detects and allocates the required power per device, optimising energy usage.
Unmatched Network Performance
The GWN7806P is built for high‑throughput environments. It features 6 x 10 Gigabit SFP+ ports for high‑speed fibre backbone links or stacking, delivering a non‑blocking switching capacity of 216 Gbps and a forwarding rate of 160.704 Mpps. These SFP+ ports offer the flexibility to connect long‑distance switch stacks or servers using fibre, or to aggregate high‑bandwidth sources without downstream bottlenecks.
Advanced Layer 2+ Management & Control
The GWN7806P provides granular control over your network, with features typically found in much higher‑priced enterprise switches:
-
VLANs (4K) : Supports port‑based VLAN, 802.1Q tagging, Voice VLAN (automatically prioritises IP phones), MAC‑based VLAN, protocol‑based VLAN, and QinQ (double tagging) for service provider deployments.
-
Network Reliability: Features 32 link aggregation groups (LACP) for bonded uplinks, advanced Spanning Tree protocols (64 instances of STP/RSTP/MSTP/PVST+) to eliminate loops, and ERPS (pending) for carrier‑grade convergence.
-
Traffic Optimisation: Advanced QoS with 8 priority queues per port, and scheduling algorithms (SP, WRR, SP+WRR) to prioritise critical voice and video traffic.
-
Rich Multicast Features: IGMP & MLD Snooping (v2/v3) for efficient distribution of multicast streams like iptv.
Enterprise‑Grade Security & Reliability
The GWN7806P includes a comprehensive security suite to protect your network from internal and external threats, safeguarding your business data and communications:
-
Port‑based Authentication: with 802.1X, MAC authentication, and AAA via RADIUS or TACACS+.
-
Attack Prevention: DHCP Snooping, Dynamic ARP Inspection (DAI), and IP Source Guard to block man‑in‑the‑middle and spoofing attacks.
-
Protection Features: DoS attack prevention, Storm Control, Port Isolation, Sticky MAC filtering, Loop protection (BPDU guard, root guard), and a Kensington lock slot for physical security.
Free, Centralised Management & Stacking
The GWN7806P offers a flexible suite of management options:
-
Stacking Support: Connect up to 16 GWN7806(P) switches using the SFP+ ports and manage them as a single logical unit from one IP address, with redundant links providing high availability.
-
GDMS Networking (Cloud) : Grandstream‘s free cloud platform for zero‑touch provisioning, real‑time monitoring, configuration, and bulk firmware upgrades across your entire fleet of switches, routers, and Wi‑Fi APs, from anywhere.
-
GWN Manager (On‑Premise) : A powerful, free software controller for enterprises that prefer to keep management local and on‑site.
-
Local Management: Web interface, command‑line interface (CLI), and SNMP v1/v2c/v3.
Key Features & Specifications at a Glance
-
48 x 10/100/1000 Mbps RJ‑45 ports with PoE+ (802.3af/at, up to 30W per port).
-
6 x 10 Gigabit SFP+ ports for fibre uplinks or stacking.
-
Switching capacity: 216 Gbps； forwarding rate: 160.704 Mpps.
-
VLAN Groups: 4K (port‑based, 802.1Q, Voice VLAN, MAC‑based, protocol‑based, QinQ).
-
Link Aggregation Groups: 32 (with LACP).
-
Spanning Tree: 64 instances for STP/RSTP/MSTP/PVST+/RPVST+.
-
Layer 3 Features: Unicast routing via ACL, DHCP server and relay.
-
Security: 802.1X, RADIUS/TACACS+, DHCP Snooping, IP Source Guard, ARP Inspection, DoS prevention.
-
Management: Web UI, CLI, SNMP v1/v2c/v3, GDMS Networking (cloud), GWN Manager (on‑premise).
-
Physical: 1U metal chassis, 5.1 kg weight, 440 x 301 x 44 mm
Technical Specifications
Frequently Asked Questions
1. How many devices can the GWN7806P handle, and what is the total PoE power budget for powering cameras and access points? +
This is a high‑density switch. You can connect up to 48 wired devices (computers, printers, servers). The 400W total PoE budget means you can power up to 48 devices simultaneously, provided the total power required does not exceed 400W. For demanding devices like PTZ cameras or Grandstream GWN7672 access points (~25W), you could power around 16 units concurrently.
2. How does the GWN7806P differ from the GWN7806 standard (non‑PoE) model? +
The GWN7806P (this product) adds 48 PoE+ ports (with 400W budget), uses a metal chassis, and comes with a high‑power 100‑240VAC power supply. The non‑PoE GWN7806 unit has a plastic chassis and lacks any PoE output, making it unsuitable for powering phones, cameras, or APs.
3. Does the GWN7806P work with Pakistan‘s 220V power supply, and what is its power consumption? +
Yes, the switch includes a built‑in power supply with universal AC input (100‑240VAC, 50‑60Hz) that works seamlessly on Pakistan’s standard 220V/50Hz grid. The device‘s total power budget for connected devices is 400W. Some distributor listings note a total power supply capacity of 470W or 640W depending on the regional SKU [4†L20], ensuring plenty of headroom for demanding networks.
4. Is this switch noisy? +
It uses active cooling via internal variable‑speed fans to keep the unit within safe operating temperatures (0 °C to 45 °C). While not silent, the noise level is designed to be acceptable for a server room or a secure network closet; it is not intended for open office desktops.
