PLC-434P-AU-WR3/PM 4MP Full Colour IP Camera | 4MP Built-In Audio Warmlight Bullet Camera | H.265 | 20-30m IR | Intrusion Detection & Line Crossing Detection | Support HLC, WDR, BLC & Defog | IP67

PLC-434P-AU-WR3PM
4MP FULL COLOUR IP CAMERA
• 4MP Built-In Audio Warmlight Bullet Camera
• H.265
• 20-30m IR
• Intrusion Detection & Line Crossing Detection
• Support HLC, WDR, BLC & Defog
• IP67 Ingress Protection

Specifications
Downloads
Model PLC-434P-AU-WR3/PM
Image sensor 1 / 3 "CMOS
Image Size 2560×1440
Electronic Shutter 1/2s ~ 1 / 100000s
Iris Type Fixed Iris
Min. Illumination 0.002 lux@ F1.0, AGC ON; 0 lux with LED ON
Lens 2.8mm@F1.6, Horizontal FoV: 94°; Vertical FoV:50°; Diagonal FoV:115° 3.6mm@F1.6, Horizontal FoV:78°; Vertical FoV:40°; Diagonal FoV:97°
Focus Fixed
Lens Mount M12
Day & Night ICR
Wide Dynamic Range 120dB
BLC Yes
HLC Yes
Digital NR Yes
Angle Adjustment Pan: 0°~360°; Tilt:0°~75°; Rotation: 0°~360°
Video Compression Main stream: H.265 / H.264 Sub stream: H.265 / H.264 / MJPEG Third stream: H.265 / H.264 / MJPEG
H.265 Compression Standard Main Profile@Leve4.1 High Tier
Resolution 4MP (2560 × 1440), 3MP (2304 × 1296), 1080P (1920 × 1080),720P (1280 × 720), D1, 480× 240, CIF
Main Stream 60Hz: 4MP/3MP/1080P/720P(1~30fps); 50Hz: 4MP/3MP/1080P/720P(1~25fps)
Sub Stream 60Hz: 720P/D1/CIF (1~30fps);50Hz: 720P/D1/CIF (1~25fps)
Third Stream 60Hz: D1/480× 240/CIF (1~30fps);50Hz: D1/480× 240/CIF(1~25fps)
Bit Rate 64 Kbps ~ 8 Mbps
Bit Rate Type VBR / CBR
Image Settings ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, Image Mirror, Image Flip, NR, etc. adjustable through client software or web browser
ROI Each ROI to be configured separately
Network RJ45
Video Output No
Audio 1CH audio input; 1CH built-in MIC
Reset Yes
Remote Monitoring PVMS Plus for Desk Top & Pollo Live Plus for Mobile
Web Browser IE (plug-in required)/Google Chrome/Edge/Firefox/Safari
Online Connection Support simultaneous monitoring for up to 3 users; Support multi-stream real time transmission
Network Protocol UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, PPPoE, DDNS, SMTP, FTP, 802.1x, SNMP, UPnP, HTTP, HTTPs, QoS
Interface Protocol ONVIF
Storage Network remote storage; micro-SD card storage
Smart Alarm Motion detection, SD card full, SD card error
Smart Event Video Exception (scene change, video blur and video cast detection), line crossing detection and region intrusion detection
General Function Watermark, IP address filtering, video mask, heartbeat, illegal login lock, corridor pattern
PoE Yes
White Light Range 20 ~ 30 m
Ingress Protection IP 67
Power Supply DC12V/PoE
Power Consumption < 5W
Operating Environment - 30 °C ~ 60 °C (-22°F~140°F); Humidity: less than 95 % (non-condensing)
Storage Environment - 30 °C ~ 65°C (-22°F~149°F), Humidity: less than 95 % (non-condensing)
Dimensions (mm) Ø 94.6 × 82.8
Weight (net) Approx. 0.46KG
Installation Ceiling mounting (Wall mounting available with the junction box and bracket)
Certificate CE, FCC
Environmental Protection Complies with Directive EU RoHS, WEEE (2012/19/EU), directive 94/62/EC and REACH(EC1907/2006)
